LABEL COMPONENTS
LGA1150 haswell socket for latest 4th Generation Intel®
Core™ Family/ Pentium®/Celeron® Processors
2. CPU_FAN 4-pin CPU cooling fan connector
3. SYS_FAN 4-pin system cooling fan connector
4. DDR3_1~4 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA_3~4 Serial ATA 3.0 Gb/s connectors
7. SATA3_1~2 Serial ATA 6.0 Gb/s connectors
8. F_PANEL Front panel switch/LED header
9. CLR_CMOS Clear CMOS jumper
10. BZ Buzzer
11. CASE CASE open header
12. ME_UNLOCK ME unlock header-for factory use only
13. F_USB1~2 Front panel USB 2.0 headers
14. TPM Trusted Platform Module header
15. COM Onboard serial port header
16. LPT Printer header
17. F_AUDIO Front panel audio header
18. PCI1~2 32-bit add-on card slots
19. PCIE1 PCI Express x1 slot
20. SPDIFO SPDIF out header
21. PCIEX16 PCI Express slot for graphics interface
22. ATX12V 4-pin +12V power connector
1. CPU Socket
