15
Installing the Motherboard
L
VDS: L
VDS connector (Optional)
Pin Signal Name Pin Signal Name
1
VDD
2
VDD
5
V_LED
6
V_LED
7
GND
8
GND
9
PWM_LED
10
EN_LED
11
USB_VCC
12
USB_D-
13
USB_D+
14
USB_GND
15
V_EDID
16
GND
17
RXIN0-
18
RXIN0+
19
GND
20
RXIN1-
21
RXIN1+
22
GND
23
RXIN2-
24
RXIN2+
3
GND
4
USB_GND
25
GND
26
RXCLK+
27
RXCLK-
28
GND
29
DAT
A-EDID
30
CLK-EDID
