ECS Liva One User Manual

23
Using BIOS


Trusted Computing
Use this item to show the information of trusted computing configuration.
TPM Support (Enabled)
Use this item to enable or disable BIOS support for security device. O.S. will not show
Security Device. TCG EFI protocol and INT1A interface will not be available.
TPM State (Enabled)
Select Enabled to display the status of TPM support for this system. Please note that
a system reboot is needed before a change on the TPM state to take effect.
Pending operation (None)
Schedule an Operation for the Security Device. NOTE:
Your Computer will
rebootduring restart in order to change State of Security Device.
Device Select (Atuo)
TPM 1.2 will restrict support to TPM 1.2 device, TPM 2.0 will restrict support to
TPM 2.0 devices, Auto will support both with default set to TPM 2.0 devices if not
found, TPM 1.2 devices will be enumerated.
Main Advanced Chipset Tweak Security Boot Exit
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
TPM Device Found
TPM Support Enabled
TPM State Enabled
Pending operation None
Platform Hierarchy Enabled
Storage Hierarchy Enabled
Endorsement Hierarchy Enabled
HashPolicy Sha-1
TPM 20 InterfaceType CRB
Device Select Auto
Platform Hierarchy (Enabled)
Use this item to enable or disable the platform hierarchy.
Storage Hierarchy (Enabled)
Use this item to enable or disable the storage hierarchy.
Endorsement Hierarchy (Enabled)
Use this item to enable or disable the Endorsement hierarchy.
HashPolicy (Sha-1)
Use this item to select the Hash policy to use. SHA-2 is most secure but might notbe
supported by all operating systems.
TPM 20 InterfaceType (CRB)
Use this item to select the communication interface to TPM 20 device.

ECS Liva One Specifications

General

SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	M.2
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	80 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Number of storage drives supported	2
Product type	Mini PC
Audio output channels	2.0 channels
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Volume	1 L
Product color	Black
Power supply	90 W
Certification	CE, FCC, BSMI
Tcase	66 °C
Bus type	DMI3
Stepping	S0
Tjunction	- °C
FSB Parity	-
Processor cache	3 MB
Processor model	i3-6100T
System bus rate	8 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-6100 Desktop series
Processor socket	LGA 1151 (Socket H4)
Processor codename	Skylake
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Configurable TDP-down	- W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor operating modes	64-bit
PCI Express configurations	2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)	35 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	64 GB
Scalability	1S
Processor code	SR2HE
Processor ARK ID	90734
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.1, AVX 2.0, SSE4.2
Thermal solution specification	PCG 2015A
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
On-board graphics card ID	1912
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 530
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	950 MHz
Number of displays supported (on-board graphics)	3
Internal memory	4 GB
Memory channels	Dual-channel
Internal memory type	DDR3L-SDRAM
Maximum internal memory	32 GB

Weight and Dimensions

Depth	173 mm
Width	33 mm
Height	176 mm
Weight	1200 g
