37
Trouble Shooting
Chapter 5
Trouble Shooting
Start up problems during assembly
After assembling the PC for the first time you may experience some start up
problems. Before calling for technical support or returning for warranty, this chapter
may help to address some of the common questions using some basic troubleshooting
tips.
a) System does not power up and the fans are not running.
1.Disassemble the PC to remove the VGA adaptor card, DDR memory, LAN, USB
and other peripherals including keyboard and mouse. Leave only the motherboard,
CPU with CPU cooler and power supply connected. Turn on again to see if the
CPU and power supply fans are running.
2. Make sure to remove any unused screws or other metal objects such as screwdrivers
from the inside PC case. This is to prevent damage from short circuit.
3. Check the CPU FAN connector is connected to the motherboard.
4. For Intel platforms check the pins on the CPU socket for damage or bent. A bent
pin may cause failure to boot and sometimes permanent damage from short circuit.
5. Check the 19V power connector is connected to the motherboard.
6. Check that the 19V power is fully inserted into the motherboard connectors.
Make sure the latches of the cable and connector are locked into place.
b) Power is on, fans are running but there is no display
1. Make sure the monitor is turned on and the monitor cable is properly connected
to the PC.
2. Check the VGA adapter card (if applicable) is inserted properly.
3. Listen for beep sounds. If you are using internal PC speaker make sure it is
connected.
a. continuous 3 short beeps : memory not detected
b. 1 long beep and 8 short beeps : VGA not detected

Other manuals for ECS Liva One

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS Liva One and is the answer not in the manual?

ECS Liva One Specifications

General IconGeneral
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfaceM.2
Storage mediaSSD
Optical drive typeNo
Card reader integratedYes
Total storage capacity80 GB
Compatible memory cardsMicroSD (TransFlash)
Number of SSDs installed1
Number of storage drives supported2
Product typeMini PC
Audio output channels2.0 channels
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Volume1 L
Product colorBlack
Power supply90 W
CertificationCE, FCC, BSMI
Tcase66 °C
Bus typeDMI3
SteppingS0
Tjunction- °C
FSB Parity-
Processor cache3 MB
Processor modeli3-6100T
System bus rate8 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-6100 Desktop series
Processor socketLGA 1151 (Socket H4)
Processor codenameSkylake
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Configurable TDP-down- W
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor operating modes64-bit
PCI Express configurations2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)35 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor1.35 V
Memory clock speeds supported by processor1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor64 GB
Scalability1S
Processor codeSR2HE
Processor ARK ID90734
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.1, AVX 2.0, SSE4.2
Thermal solution specificationPCG 2015A
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
On-board graphics card ID1912
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 530
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)950 MHz
Number of displays supported (on-board graphics)3
Internal memory4 GB
Memory channelsDual-channel
Internal memory typeDDR3L-SDRAM
Maximum internal memory32 GB
Weight and Dimensions IconWeight and Dimensions
Depth173 mm
Width33 mm
Height176 mm
Weight1200 g
