ECS Motherboard Manual

5
Introducing the Motherboard
Table of Motherboard Components
LABEL COMPONENTS
AMD Phenom
TM
p
rocessor
(
socket AM2+
)/
AMD Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/
Sem
p
ron™
p
rocessors
2. CPU_FAN
CPU cooling fan connector
3. SYS_FAN
System cooling fan connector
4. DDR2_1~2
240-pin DDR2 SDRAM slots
5. ATX_POWER
Standard 24-pin ATX power connector
6. IDE1
Primary IDE connector
7. SATA1~6
Serial ATA connectors
8. CLR_CMOS
Clear CMOS jumper
9. F_PANEL
Front panel switch/LED header
10. SPK
Speaker header
11. LPT
Parallel port header
12. USBPWR_F2
Front Panel USB Power Select Jumper
13. USBPWR_F1
Front Panel USB Power Select Jumper
14. F_USB1~3
Front Panel USB headers
15. IR
Infrared header
16. SPDIFO
SPDIF out header
17. CD_IN
Analog audio input header
18. F_AUDIO
Front panel audio header
19. PCI1~2
32-bit add-on card slots
20. PCIEX
PCI Express x1 slot
21. PCIEX16
PCI Express x16 slot for graphics interface
22. USBPWR_R1
Rear USB/PS2 Power Select Jumper
23. ATX12V
4-pin +12V power connector
1. CPU Socket
This concludes Chapter 1. The next chapter explains how to install the motherboard.
