Using BIOS
Standard CMOS Setup
This option displays basic information about your system.
Date Fri 12/07/2007
f
SATA1 Not Detected
SATA 2 Not Detected
SATA 3 Not Detected
SATA 4 Not Detected
SATA5 Not Detected
SATA6 Not Detected
IDE Master Not Detected
IDE Slave Not Detected
IDE BusMaster Enabled
Help Item
f
f
f
CMOS Setup Utility -- Copyright (C) 1985-2007, American Megatrends, Inc.
Time 00:11:10
User [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
Standard CMOS Setup
Date & Time
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the Windows Date and Time Properties utility.
SATA1
f
This motherboard supports six SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
CMOS SETUP UTILITY – Copyright (C) 1985-2007, American Megatrends, Inc.
SATA1
SATA1
LBA/Large Mode Auto
Block (Multi-Sector Transfer) Auto
PIO Mode Auto
DMA Mode Auto
S.M.A.R.T Auto
32Bit Data Transfer Enabled
Help Item
Disabled: Disables LBA
Mode.
Auto: Enables LBA
Mode if the device
supports it and the
device is not already
formatted with LBA
Mode disabled.
Device : Not Detected
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
f
f
f
f
LBA/Large Mode (Auto)
Use this item to set the LAB/Large mode to enhance hard disk performance by
optimizing the area the hard disk is visited each time.
