ECS Motherboard Manual

2
Introducing the Motherboard
Feature
Processor
HyperTransport
TM
Technology is a point-to-point link between two devices, it
enables integrated circuits to exchange information at much higher speeds than
currently available interconnect technologies.
• Accommodates AMD Phenom
TM
processor (socket AM2+)
AMD Athlon
TM
64 X2 Dual-Core/Athlon
TM
64/Sempron™ processors
• Supports HyperTransport
TM
(HT) 1.0 interface speeds
This motherboard uses a Socket AM2+ that carries the following features:
Audio (Optional)
The onboard Audio provides the following features:
• 5.1 Channel High Definition Audio Codec
• DACs Support 96K/48K/44.1KHz DAC sample rate
• Power support: Digital:3.3V; Analog:5.0V
• WOW
TM
and Tru Surround
TM
from SRS
• Provides single ended CD input with DRM solutions and legacy
OS issues
SB700 (SB)
AMD 740G
(NB)
• One x4 A-Link Express II interface (PCI Express 1.1
compliant) for connection to an AMD Southbridge
• Supports one PCI Express x16 for Graphics Interface,
fully compliant to the PCI Express Base Specification
revision 1.1
• Fully supports ACPI states S0, S1,S2, S3, S4, and S5
• Single chip solution in 80nm, 1.2 V CMOS technology
The AMD 740G Northbridge (NB) and SB700 Southbridge (SB) chipsets are
based on an innovative and scalable architecture with proven reliability and
performance.
Chipset
• Compliant with PCI 2.3 specification at 33 MHz
• Supports six Serial ATA devices which speeds up to 3.0
Gb/s
• Integrated USB 2.0 Host Controller supporting up to ten
USB 2.0 ports
• Integrated IDE controller supports Ultra ATA 133/100/66/
33 modes
Memory
• Supports DDR2 800/667/533/400 DDR SDRAM with Dual-channel
architecture
• Accommodates two unbuffered DIMMs
• Up to 8 GB per DIMM with maximum memory size up to 16 GB
• 7.1 Channel High Definition Audio Codec
• SPDIF In/Out supports 96K/48K/44.1KHz plus SPDIF OUT sup-
ports 88.2 KHz
• Power support: Digital:3.3V; Analog:5.0V
• MAxx Player
TM
from Waves
• Provides single ended CD input with DRM solutions and legacy
OS issues
This board supports CPU up to 95W TDP only.
