37
Using BIOS
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
• CPU Tcontrol
• CPU FAN Speed
• CPU Vcore
• VDIMM
Press <Esc> to return to the PC Health Status page.
DeltaT (+3)
SMART Fan Slope PWM value (5 PWM value/°C)
Press <Esc> to return to the main menu setting page.
Warning Temperature (Disabled)
This item enables or disables the warning temperature.
Shutdown Temperature (Disabled)
Enable you to set the maximum temperature the system can reach before powering
down
This item specifies the range that controls CPU temperature and keeps it from going
so high or so low when smart fan works.
This item is used to set the Slope Select PWM of the smart fan.
To Next Page
