ECS NFORCE4M-A User Manual

15
Installing the Motherboard
Table B: DDR2 (memory module) QVL (Qualified Vendor List)
The following DDR2 memory modules have been tested and qualified for use with this
motherboard.
Table A: Unbuffered DIMM Support for Socket AM2 CPU
DRAM
Speed
DIMM1
1
DIMM2
1
Timing
Mode
Address Timing
Control Register
Output Driver
Compensation
Control Register
DDR2-400 - Any 1T 002F_2F2Fh X011_1222h
DDR2-400 Any Any 2T 002F_2F2Fh X011_1322h
DDR2-533 - Any 1T 002F_2F2Fh X011_1222h
SRx16 SRx16
SRx16 SRx8
DDR2-533
SRx8 SRx16
2T 002F_2F2Fh X011_1322h
DDR2-533 SRx8 SRx8 2T 0000_2F2Fh X011_1322h
DDR2-533 DRx8 DRx8 2T 0034_2F2Fh X011_1322h
DRx8 SRx16
DDR2-533
SRx16 DRx8
2T 0038_2F2Fh X011_1322h
DRx8 SRx8
DDR2-533
SRx8 DRx8
2T 0037_2F2Fh X011_1322h
DDR2-667 - Any 1T 0020_2020h X011_1222h
SRx16 SRx16
SRx16 SRx8
DDR2-667
SRx8 SRx16
2T 0020_2020h X011_1322h
DDR2-667 SRx8 SRx8 2T 0030_2020h X011_1322h
DDR2-667 DRx8 DRx8 2T 002B_2020h X011_1322h
DRx8 SRx16
DDR2-667
SRx16 DRx8
2T 002C_2020h X011_1322h
DRx8 SRx8
DDR2-667
SRx8 DRx8
2T 002A_2020h X011_1322h
DDR2-800 - Any 2T 0020_2520h X011_3222h
DDR2-800 Any Any 2T 0020_2520h X011_3222h
1. SRx16=Single Rank x16 DIMM
SRx8=Single Rank x8 DIMM
DRx16=Dual Rank x16 DIMM
DRx8=Dual Rank x8 DIMM
Type Size Vendor Module Name
Samsung PC2-3200U-333-10-A1 K4T51083QB-GCCC
DDR2 400 512 MB
Samsung PC2-3200U-333-10-A1 K4T5163QB-ZCCC
Corsair VC256MB533D2 4PB11D9CHM
Eipida 04180WB00
256 MB
Kingston Infioeon KVR533D2N4/256 HYB18T512260AF-3.7
Corsair 0434028-0 4PB11D9CHM
Eipida Eipida 04180WB01
Kingston Hynix KVR533D2N4/512 HY5PS12821
Kingston Hynix KVR533D2N4/512HY5PS56821
Samsung PC2-4200U-4444-12-DS K4T51083QC
Samsung PC2-4200U-4444-10-B1 K4T51083QF-ZC05
Twinmos Hynix 8D22JB-HX
512 MB
Twinmos Elpida 8D22JB-ED
Apacer Eipida E5108AB-5C-E
DDR2 533
1 GB
Geil A016E2864T2AG8AK AG8AKT5H120004
256 MB
Infineon HYS64T325001HU-3-A HYB18T256
A-DATA Eipida 04230W324 E5108AB-5C-E
Corsair VALUESELECT 32M8CEC
Infinity 0547W64M8PC5300
Samsung PC35300U-25331-Z K4T56083QF-ZCE6
Syncmax Elpida04230W324 E5108AB-5C-E
DDR2 667
512 MB
Transcend SEL520ZC6 K4T51083QC
