Using BIOS
Integrated Peripherals
These options display items that define the operation of peripheral components on
the system’s input/output ports.
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Integrated Peripherals
mnlk
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Item Help
f
Menu Level
f
f
IDE Function Setup [Press Enter]
RAID Config [Press Enter]
Onboard Device [Press Enter]
SuperIO Device [Press Enter]
IDE HDD Block Mode [Enabled]
f
f
IDE Function Setup (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Item Help
ff
Menu Level
Phoenix-Award WorkstationBIOS CMOS Setup Utility
IDE Function Setup
OnChip IDE Channel0 [Enabled]
Primary Master PIO [Auto]
Primary Slave PIO [Auto]
Primary Master UDMA [Auto]
Primary Slave UDMA [Auto]
OnChip IDE Channel1 [Enabled]
Secondary Master PIO [Auto]
IDE Secondary Slave PIO [Auto]
Secondary Master UDMA [Auto]
Secondary Slave UDMA [Auto]
IDE DMA transfer access [Enabled]
Serial-ATA Controller [All Enabled]
IDE Prefetch Mode [Enabled]
On-Chip IDE Channel 0/1 (Enabled)
Use these items to enable or disable the PCI IDE channels that are integrated on the
motherboard.
Primary/Secondary Master/Slave PIO (Auto)
Each IDE channel supports a master device and a slave device. These four items let you
assign the kind of PIO (Programmed Input/Output) was used by the IDE devices. Choose
Auto to let the system auto detect which PIO mode is best, or select a PIO mode from 0-4.
