ECS NFORCE4M-A - PC Health Status

43
Using BIOS
PC Health Status
On motherboards that support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Phoenix-Award WorkstationBIOS CMOS Setup Utility
PC Health Status
Item Help
f
Menu Level
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Smart Fan Function [Press Enter]
Shutdown Temperature [Disabled]]
Warning Temperature [Disabled]
CPU Tcontrol 45
o
C
System Temperature 27
o
C
CPU Fan Speed 4800 RPM
System Fan Speed 0 RPM
CPU Vcore 1.39V
VDIMM 1.85V
f
Smart Fan Control (Auto)
This item allows you to enable/disable the control of the system fan speed by changing by
changing the fan voltage.
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Smart Fan Function
f Smart Fan Function (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
mnlk
X
Item Help
ff
Menu Level
: Move PU/PD+/-/:Change Priority F10:Save ESC:Exit
Smart Fan Control [Auto]
FAN1 START PWM VALUE 0
FAN1 START Temp
o
C 0
FAN1 Limit Temp
o
C 0
FAN1 Slope Select PWM/
o
C 0
X
X
X
