Installing the Motherboard
SPDIFO1: SPDIF out header
This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface) output
to digital multimedia device through optical fiber or coaxial connector
.
2
+5VA
5V
analog Power
3
Ke
y
No
p
i
n
4
GN
D
Ground
Pin
Signal Name Function
1
SPDIF
SPDIF digital output
