PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset Tweak Boot Security Exit
System Temperature : 41
O
C
CPU Fan Speed : 2599 RPM
System Fan Speed : 0 RPM
CPU Voltage : 1.008 V
DIMM Voltage : 1.536 V
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -49
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
PC Health Status
• System Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Voltage
•
DIMM Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press <Esc> to return to the Advanced Menu page.
