Chapter 1
2
NM70-TI USER MANUAL
CPU
Specifications
• Intel
®
NM70 Chipset
Chipset
• Dual channel DDR3 SO-DIMM memory architecture
• 2 x 204-pin DDR3 SO-DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x1 slot (Optional)
• 2 x mini PCI Express x1 Gen2 slots
(one supports half-card, the other supports full-card.)
• Supported by Intel
®
NM70 Express Chipset
- 2 x Serial ATA 3.0Gb/s devices
- 1 x Serial ATA 6.0Gb/s device
Expansion
Slots
Storage
• 1 x DC-IN port
• 1 x D-Sub port (VGA)
• 1 x HDMI port
• 2 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (1x Line out, 1x Mic_in Rear)
Rear Panel I/O
LAN • Realtek 8111E Gigabit Lan (Co-lay Realtek 8105E)
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Intel
®
Onboard ICP1037U/ICP847/ICP807 CPU
• Intel TDP 17W
• 1 x 4-pin CPU_FAN connector with smart fan
• 1 x 4-pin SYS_FAN connector with smart fan
• 1 x USB 2.0 header supports additional two USB 2.0 ports
• 2 x Serial SATA 3.0Gb/s connectors
• 1 x Serial SATA 6.0Gb/s connector
• 1 x COM header (Optional)
• 1 x LVDS connector (Optional)
• 1 x SATA power connector
• 1 x Case open header
• 1 x ME unlock header
• 1 x Display brightness connector (Optional)
• 1 x SPDIF out header (Optional)
• 1 x Speaker header
• 1 x Buzzer header
• 1 x Camera header (or can be functioned as a USB2.0 header)
• 1 x Touch panel header (or can be functioned as a USB2.0
header)
• 1 x Card reader header (or can be functioned as a USB2.0
header)
• 1 x CIR header (Optional)
• 1 x Digital Mic header (Optional)
• 1 x LCD select jumper header (Optional)
Internal I/O
Connectors &
Headers
• Realtek ALC662
- 6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
To Next Page
