SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (AHCI Mode)
Use this item to select SATA mode.
SATAIII/SATAII Port1~2/mSATA
This motherboard supports three SATA channels and one mSATA channel, each chan-
nel allows one SATA/mSATA device to be installed. Use these items to configure each
device on the SATA/mSATA channel.
Press <Esc> to return to the Advanced Menu page.
SATA Configuration
SATA Mode [AHCI Mode]
SATAIII MAXTOR STM3250 (250.0GB)
Spin Up Device [Disabled]
External SATA [Disabled]
SATAII Port1 PIONEER DVD-RW ATAPI
Spin Up Device [Disabled]
External SATA [Disabled]
SATAII Port2 Empty
Spin Up Device [Disabled]
External SATA [Disabled]
mSATA Empty
Spin Up Device [Disabled]
External SATA [Disabled]
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012 American Megatrends, Inc.
Determines how SATA controller(s)
operate.
Main Advanced Chipset Tweak Boot Security Exit
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Spin Up Device (Disabled)
Use this item to enable or disable the spin up device.
External SATA (Disabled)
Use this item to enable or disable the external SATA.
