NM70-TI USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL
COMPONENTS
1. CPU
Onboard ICP1037U/ICP847/ICP807 CPU
2. DIMM_1~2
Two 204-pin DDR3 SDRAM SO-DIMMs
3. BT
Battery connector
4. BZ
Buzzer header
5. PCIE
PCI Express x1 slot (optional)
6. SPKR
Internal speaker header
7. DMIC
Digital Microphone header (optional)
8. SPDIFO
SPDIF out header (optional)
9. F_AUDIO
Front panel audio header
10. CLR_CMOS
Clear CMOS jumper
11. LCD_SEL
LCD select jumper (optional)
12. LDC
Debug Card Header
14. F_USB
Front panel USB 2.0 header
15. SATA6G_1
Serial ATA 6.0 Gb/s connector
16. SATA3G_1/2
Serial ATA 3.0 Gb/s connectors
17. USB_CAM
CCD header
18. USB_TP
Touch panel header
19. SATA_PWR
SATA power connector
20. USB_CR
Card reader header
21. SYS_FAN
4-pin system cooling fan connector
22. MON_SW
Monitor switch header
23. CPU_FAN
4-pin CPU cooling fan connector
24. F_PANEL
Front panel switch/LED header
25. CASE
CASE open header
26. LVDS
LVDS header (optional)
27. DISP_BRT
Display brightness header (optional)
28. ME_UNLOCK
ME unlock header
29. CIR
Consumer Infrared header (optional)
30. COM
Onboard serial port header (optional)
13. MPE1~2
Mini PCI Express x1 slots(one supports half-card, and
the other supports full-card; full-card slot can also
support mSATA)
