OnBoard FDC
Use this item to enable or disable the onboard floppy disk drive interface.
OnBoard Serial PortA
Use this item to enable or disable the onboard COM1 serial port, and to as-
sign a port address.
OnBoard IR Port
Use this item to enable or disable the onboard infrared port, and to assign a
port address.
Parallel Port Mode
Use this item to set the parallel port mode. You can select SPP (Standard
Parallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel
Port), or ECP + EPP.
Parallel Port IRQ
Use this item to assign IRQ to the parallel port.
Parallel Port DMA
Use this item to assign a DMA channel to the parallel port.
OnBoard Game Port
This item enables or disables the I/O address for the game port.
OnBoard MIDI Port
Use this item to enable or disable the onboard MIDI port, and to assign a port
address.
MIDI Port IRQ
Use this item to assign IRQ 7 to the parallel port.
OnBoard IDE
Use this item to enable or disable the onboard IDE channel.
Audio Device
This item enables or disables the AC’97 audio chip.
Modem Device
This item enables or disables the MC’97 modem chip.
Ethernet Device
This item enables or disables the onboard Ethernet LAN.
USB Controller
Use this item to select the USB ports or disabled.
USB Device Legacy Support
This item allows you to enable the USB device, if you have installed a USB
device on the system board.
29
