Page #32 background imageLoading...
Page #32 background image
use of a second display card installed in a PCI slot.
Allocate IRQ for PCI VGA
If this item is enabled, an IRQ will be assigned to the PCI VGA graphics sys-
tem. You set this value to No to free up an IRQ.
PCI IDE BusMaster
This item enables or disables the DMA under DOS mode. We recommend you
to leave this item at the default value.
Load Optimal Settings
If you select this item and press Enter a dialog box appears. If you press Y,
and then Enter, the Setup Utility loads a set of fail-safe default values. These
default values are not very demanding and they should allow your system to
function with most kinds of hardware and memory chips.
Note: It is highly recommended that users enter this option to load optimal
values for accessing the best performance.
Load Best Performance Settings
If you select this item and press Enter a dialog box appears. If you press Y,
and then Enter, the Setup Utility loads a set of best-performance default val-
ues. These default values are quite demanding and your system might not
function properly if you are using slower memory chips or other low-
performance components.
Features Setup Page
This page sets up some parameters for those peripheral devices connected to
the system.
AMIBIOS SETUP – FEATURES SETUP
©2000 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Enabled
OnBoard Serial PortA 3F8h/COM1
OnBoard IR Port Disabled
OnBoard Parallel Port 378h
Parallel Port Mode SPP
Parallel Port IRQ 7
Parallel Port DMA N/A
OnBoard Game Port 201h
OnBoard MIDI Port 300h
MIDI Port IRQ 10
OnBoard IDE Both
Audio Device Enabled
Modem Device Auto
Ethernet Device Enabled
USB Controller Enabled
USB Device Legacy Support Disabled
ThumbDrive Support for DOS Disabled
ESC : Quit ↑↓←→ : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
28
