Using BIOS
Press <Esc> to return to the Integrated Peripherals page.
Onboard FDC Controller (Enabled)
This option enables the onboard floppy disk drive controller.
Onboard Serial Port1 (3F8/IRQ4)
This option is used to assign the I/O address and interrupt request (IRQ) for onboard serial
port 1 (COM1).
Onboard Parallel Port (378/IRQ7)
This option is used to assign the I/O address and interrupt request (IRQ) for the onboard
parallel port.
Parallel Port Mode (ECP)
Enables you to set the data transfer protocol for your parallel port. There are four options:
SPP (Standard Parallel Port), EPP (Enhanced Parallel Port), ECP (Extended Capabilities
Port) and ECP+EPP.
SPP allows data output only. Extended Capabilities Port (ECP) and Enhanced Parallel Port
(EPP) are bi-directional modes, allowing both data input and output. ECP and EPP modes
are only supported with EPP- and ECP-aware peripherals.
USB Mouse Support (Enabled)
Enables this item if you plan to use a mouse connected through the USB port in a legacy
operating system (such as DOS) that does not support Plug and Play.
!
SuperIO Device (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Onboard FDC Controller [Enabled]
Onboard Serial Port1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [ECP]
ECP Mode Use DMA [3]
Phoenix-AwardBIOS CMOS Setup Utility
Super IO Device
Item Help
Menu Level
!
!
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
"#$%
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
ECP Mode Use DMA (3)
When the onboard parallel port is set to ECP mode, the parallel port can use DMA 3 or
DMA 1.
Press <Esc> to return to the Integrated Peripherals page.
