ECS PM800-M2 User Manual

43
Using BIOS
PC Health Status
On motherboards that support hardware monitoring, this item lets you monitor the param-
eters for critical voltages, critical temperatures, and fan speeds.
Shutdown Temperature [Disabled]
CPU Vcore 1.68V
2.50 V 2.51V
3.30 V 3.34V
5.00 V 5.10V
12.00 V 11.84V
Voltage Battery 8.23V
Current System Temp 34°C
Current CPU Temp 29°C
CPU FAN Speed 2960 RPM
CASE FAN Speed 0 RPM
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
Item Help
!
Menu Level
"#$%
F5:Previous Values F6”Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Shutdown Temperature (Disabled)
Enables you to set the maximum temperature the system can reach before powering down.
System Component Characteristics
These items allow end users and technicians to monitor data provided by the
BIOS on this motherboard. You cannot make changes to these fields.
• CPU Vcore
• Voltage Battery
• Current System Temp
• Current CPU Temp
• CPU FAN Speed
• CASE FAN Speed
Frequency/Voltage Control
This item enables you to set the clock speed and system bus for your system. The clock
speed and system bus are determined by the kind of processor you have installed in your
system.
Phoenix-AwardBIOS CMOS Setup Utility
Frequency/Voltage Control
Item Help
!
Menu Level
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
"#$%
F5:Previous Values F6”Fail-Safe Defaults F7:Optimized Defaults
CPU Clock Ratio [10X]
Auto Detect PCI/DIMM Clk [Enabled]
Spread Spectrum [Enabled]
CPU Clock [100MHz]
CPU Voltage Regulator [Default]
DDR Voltage Regulator [Default]
