53
VIA VT8237 SATA RAID Setup Guide
Create Array
1 In the VIA RAID BIOS utility main menu, select Create Array then press the
<Enter> key. The main menu items on the upper-left corner of the screen are
replaced with create array menu options.
RAID 0 for performance
1 Select the second option item Array Mode, then press the <Enter> key. The
RAID system setting pop-up menu appears.
2 Select RAID 0 for performance from the menu and press <Enter>. From this
point, you may choose to auto-configure the RAID array by selecting Auto
Setup for Performance or manually configure the RAID array for stripped
sets. If you want to manually configure the RAID array continue with next
step, otherwise, proceed to step #5.
3 Select Select Disk Drives, then press <Enter>. Use arrow keys to select
disk drive/s, then press <Enter> to mark selected drive. An asterisk is placed
before the selected drive.
4 Select Block Size, then press <Enter> to set array block size. Lists of valid
array block sizes are displayed on a pop-up menu.
For server systems, it is recommended to use a lower
array block size. For multimedia computer systems used
mainly for audio and video editing, a higher array block
size is recommended for optimum performance.
Use arrow keys to move selection bar on items and press <Enter> to select.
Tip
