ECS RC410-M2 User Manual

33
Using BIOS
Integrated Peripherals
This page sets up more Integrated Peripherals about your system. Handle this page with
caution. Any changes can affect the operation of your computer.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2004, American Megatrends, Inc.
Integrated Peripherals
Legacy USB Support [Enabled]
USB 2.0 Support [Enabled]
USB Controller [Enabled]
USB Keyboard Support [Enabled]
USB Mouse Support [Enabled]
AC97 & Azalia LINK A [Enabled]
Onboard LAN function [Enabled]
Onboard LAN boot ROM [Disabled]
Onboard 1394 Controller [Enabled]
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [Disabled]
Parallel Port Address [378]
Parallel Port Mode [ECP]
ECP Mode DMA Channel [DMA3]
Parallel Port IRQ [IRQ7]
: Move
F10: Save
F1: General help

+/-/: Value
Enter : Select
ESC: Exit
F9: Optimized Defaults
F8: Fail-Safe DefaultsF7:Previous Values
USB 2.0 Support (Enabled)
This item allows users to enable or disable the USB 2.0 Support function.
USB Controller (Enabled)
This item allows users to enable or disable the onboard USB Controller function.
USB Keyboard Support (Enabled)
This item allows users to enable or disable the USB Keyboard Support.
USB Mouse Support (Enabled)
This item allows users to enable or disable the USB Keyboard Support.
AC97 & Azalia LINK A (Enabled)
This item allows users to enable or disable the onboard AC97 & Azalia audio.
Onboard LAN function (Enabled)
This item allows users to enable or disable the onboard LAN function.
Onboard LAN boot ROM (Disabled)
This item allows users to enable or disable the onboard LAN boot ROM function.
Onboard 1394 Controller (Enabled)
This item allows users to enable or disable the onboard 1394 Controller function.
Serial Port1/2 Address (3F8/IRQ4/Disabled)
This item allows users to manually set the address for Serial Port1 & Port2.
Parallel Port Address (378)
This item allows users to manually set the address for Parallel Port.
Legacy USB Support (Enabled)
This item allows users to enable or disable the Legacy USB Support function.
