3
Introducing the Motherboard
Onboard LAN (Optional)
This motherboard supports the following LAN with following features:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memroy timing
Some hardware specifications and software items are subject to change
with out prior notice.
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
The firmware can also be used to set parameters for different processor clock speeds.
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port
• One VGA port
• Four USB ports
• One 1394a port (optional)
• One LAN port (optional)
• Audio jacks for microphone, line-in and 8-channel High Definition audio
output
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
The RC410-M2 motherboard supports UltraDMA bus mastering with transfer rates of
133/100/66/33 MB/s.
The motherboard comes with the following expansion options:
Expansion Options
• One PCI Express x16 for Graphic Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• Two 40-pin IDE connectors supporting up to 4 IDE devices
• One floppy disk drive interface
• Four 7-pin SATA connectors
• Integrated 10/100/1000 transceiver
• Supports PCI rev. 2.3, 32-bit, 33/66MHz
• Fully compliant with IEEE 802.3z
• Wake-on-LAN and remote wake-up support
1394a FireWire (Optional)
• Fully compliant with provisions of IEEE Std 1394-1995 for a high-perfor-
mance serial bus and IEEE Std 1394a-2000
• Two IEEE Std 1394a-2000 fully compliant cable ports at 400M bits/s
