1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing TIGT-I2 motherboard of great performance and with en-
hanced function. This motherboard has onboard Intel
®
Atom
TM
D410 CPU with an
ITX form factor of 170 x 170 mm.
This motherboard is based on Intel
®
NM10 Chipset for best desktop platform solu-
tion. NM10 is a single-chip, highly integrated, high performance Hyper-Threading
peripheral controller, unmatched by any other single chip-device controller. This
motherboard supports up to 4 GB of system memory with single channel DDR2 800/
667 MHz. In addition, one PCI Express x1 slot is supported. It implements an EHCI
compliant interface that provides eight USB 2.0 ports (four USB ports and two USB
2.0 headers support additional four USB ports).
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including PS/2 mouse and keyboard connectors, one LPT port, one serial port, one
VGA port, four USB ports, one LAN port and audio jacks for microphone, line-in and
line-out.
