2
Introducing the Motherboard
Feature
• Onboard Intel
®
Atom
TM
D410 CPU
• Supports “Hyper-Threading” technology CPU
Processor
Chipset
• Supports DDR2 800/667 DDR2 SDRAM
•Accommodates two unbuffered DIMMs
• Maximum memory size up to 4 GB
Memory
Audio
• 5.1 Channel High Definition Audio Codec
• ADCs support 44.1k/48k/96kHz sample rate
• Meets Microsoft WLP 3.10 Vista premium and mobile PCs audio re-
quirements
• Direct Sound 3D
TM
compatible
The onboard Audio provides the following features:
“Hyper-Threading” technology enables the operating system into thinking it’s
hooked up to two processors, allowing two threads to be run in parallel, both on
separate “logical” processors within the same physical processor.
This motherboard uses onboard Intel
®
Atom
TM
D410
CPU that carries the following
features:
The Intel NM10 Chipset is a single-chip with proven reliability and performance.
• Integrated SATA 3.0 Gb/s Host Controller
• Eight USB 2.0 ports supported
• Serial Peripheral Interface (SPI) support
• Enhanced DMA Controller, interrupt controller, and timer functions
• Intel
®
High Definition Audio Interface
• Supports PCI Express 1.0a
• Integrated LAN Controller
Onboard LAN (optional)
The onboard LAN controller provides either of the following features:
• Supports PCI Express
TM
1.1
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
• Supports PCI Express
TM
1.1
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
