ECS Z77H2-AX - Connecting Case Components

Chapter 2
24
Z77H2-AX USER MANUAL
After you have installed the motherboard into a case, you can begin connecting the
motherboard components. Refer to the following:
2-3-7. Connecting Case Components
No. Components
1CPU_FAN
2PWR_FAN
3ATX_POWER
4F_PANEL
5SYS_FAN
6 ATX_12V
