Chapter 3
Z77H2-AX USER MANUAL
52
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B X (MB Intelligent BIOS X) Menu
CPU OverClocking
Configuration
Main Advanced Chipset M.I.B X Boot Security Exit
M.I.B X (MB Intelligent BIOS X)
CPU OverClocking Configuration
Chipset OverClocking Configuration
Quick OC
B.O.M.P. Technology Enabled
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enbaled
CPU Voltage Auto
AXG Voltage Auto
IMC Voltage Auto
DIMM Voltage Auto
System Agent Voltage Auto
PCH Voltage Auto
CPU PLL Voltage Auto
Genuine Intel(R) CPU @ 2.20GHz
Processor Speed 2200 MHz
Memory Frequency 1333 MHz
Total Memory 2048MB (DDR3 )
CPU Current Voltage 0.888V
AXG Current Voltage 0.012V
IMC Current Voltage 1.044V
DIMM Current Voltage 1.560V
PCH Current Voltage 1.056V
+/- : Change Opt.
Enter/Dbl Click : Select
lk
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
mn
CPU OverClocking Configuration
Scroll to this item to view the following screen:
CPU Frequency
Maximum supported
frequency 150.00 MHz
Minimum supported
frequency 99.54 MHz
Main Advanced Chipset M.I.B X Boot Security Exit
CPU OverClocking Configuration
CPU Frequency(1/100 MHz) 10000
CPU Ratio 23
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Runtime Turbo Enable Disabled
Over Clocking Extra Vol.(1/256 V) 0
IA Core Current Max(1/8 Amp) 1680
iGFX Core Current Max(1/8 Amp) 800
Long Duration Power Limit Override 1440
Long Duration Maintained 10
Short Duration Power Limit Override 1680
1 Core Ratio Limit 33
2 Core Ratio Limit 33
3 Core Ratio Limt 32
4 Core Ratio Limit 31
+/- : Change Opt.
Enter/Dbl Click : Select
lk
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
mn
