PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
 Smart Fan Function
Main Advanced Chipset M.I.B. X Security Boot Exit
SmartFan Select
Main Advanced Chipset M.I.B. X Security Boot Exit
Smart Fan Select CPU Fan 1
Smart Fan Mode Normal
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (DTS) 70
DeltaT 3
Smart Fan Slope PWM value 10
Fan Full Speed Offset (DTS) 77
CPU Temperature (DTS) : 42
System Temperature : 30
O
C
CPU Fan 1 Speed : 3308 RPM
CPU Fan 2 Speed : 0 RPM
System Fan 1 Speed : 0 RPM
System Fan 2 Speed : 0 RPM
System Fan 3 Speed : 0 RPM
Core Voltage : 1.020V
DIMM Voltage : 1.512V
+12V : 11.880V
+5V : 5.124V
+3.3V : 3.396V
PCH Core Voltage : 1.068V
TCC Activation Temperature (DTS) 100
Smart Fan Function
PC Health Status
