ECS Z97 MACHINE - Connecting Optional Devices

Chapter 2
16
Z97-MACHINE USER MANUAL
2-4-5. Connecting Optional Devices
Refer to the following for information on connecting the motherboard’s optional
devices:
No. Components No. Components
1 USB3F 4 F_USB
2 SATA3_1~4 5 F_AUDIO
3 CASE6SPDIFO
