ECS Z97 MACHINE User Manual

Chapter 1
2
Z97-MACHINE USER MANUAL
CPU
Specifications
• Intel
®
Z97 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3 3000+(OC)/2133(OC)/1866(OC)/1600 MHz
SDRAM
Memory
• Supported by Intel
®
Z97 Express Chipset
- 4 x Serial ATA 6Gb/s devices
- RAID 0, RAID 1, RAID 5, RAID 10 configuration
Expansion
Slots
Storage
• 1 x PS/2 Combo & USB connectors
• 1 x D-sub (VGA port)
• 1 x DVI port
• 1 x HDMI port
• 4 x USB 2.0 ports
• 4 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio jacks (1 x line in, 4 x line out, 1 x Optical SPDIF Out)
Rear Panel I/O
LAN • Intel I218-V Gigabit Lan
• Realtek ALC1150 8-Ch High Definition audio CODEC
- Compliant with HD audio specification
- ESS ES9010K2M DAC IC provides SABRE
32
Technology for
headphone listening
Audio
• LGA1150 socket for
4
th
and 5
th
Generation Intel
®
Core
TM
processors
• Supports max CPU TDP 84W and MB TDP designs up to 125W
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
AMDCrossFireX
TM
Technology
• Supports AMD CrossFireX
TM
Technology
• 2 x PCI Express x16 Gen3 slots*
• 3 x PCI Express x1 Gen2 slots
• 1 x M.2 slot for 2242/2260/2280 SATA or PCIE M.2 SSD
Internal I/O
Connectors &
Headers
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin ATX 12V Power connector
• 2 x 4-pin CPU_FAN connectors
• 2 x 4-pin SYS_FAN connectors
• 1 x 3-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 1 x USB 2.0 header supports additional two USB 2.0 port
(supports EZ charger)
Note:
*The PCIEX16_2 slot supports PCI-E Gen 3.0 running at X8 mode
and shares bandwidth with the PCIEX16_1 slot.
*If installing two graphic cards into PCIEX16_1 and PCIEX16_2
slots, both two slots will run at X8 mode.
