Z97-MACHINE USER MANUAL
Chapter 6
Chapter 6
Intel
®
Rapid Storage Technology RAID Configuration
The Intel
®
Rapid Storage Technology allows you to configure RAID 0, and 1 sets on the
external Serial ATA hard disk drives.
1. Install the external Serial ATA hard disk drive (HDD) on your system.
2. Set the SATA Mode item in the BIOS from “IDE Mode” to “RAID Mode”
See section “SATA Configuration” for details.
Before creating a RAID set
1. One SATA HDD.
2. A write-enabled floppy disk.
3. Microsoft
®
Windows
®
OS installation disk (Windows 7/8/8.1).
4. Motherboard support CD with Intel
®
Rapid Storage Technology RAID driver.
Complete the following steps before you create a RAID set:
Prepare the following items:
Determines how SATA
controller(s) operate.
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
SATA Configuration
SATA Mode RAID Mode
SATA Port1
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port2
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port3
Not Present
Spin Up Device Disabled
External SATA Disabled
SATA Port4
Not Present
Spin Up Device Disabled
External SATA Disabled
