Front view: CSI 15, CSI 20 and CSI 25
1. Switch ECO/OFF/UPS
2. LED „Power“
3. LED „Fault“
4. LED „Charge“
5. LED „AC-In“
6. LED „By-Pass“
7. Remote control port
8. USB-port
9. Shore power
10. Protective earthing
11. Fuse
12. 230 V power socket
87
3
2
9
10
1
5
6
11
4
12 12
