ECTIVE CSI34 User Manual

[
ECTIVE
®
SINUS/SINE INVERTER – CSI-/SSI-SERIES
]
36
Contin-
uous
output
Model
CSI-/SSI
Input
voltage
recommended
battery cabel*
Battery
capacity**
1500 W 152 12 V 10 mm², 2 sets ≥250 Ah
154 24 V 6 mm², 2 sets ≥125 Ah
158 48 V 4 mm², 2 sets ≥60 Ah
2000 W 202 12 V 16 mm², 2 sets ≥320 Ah
204 24 V 10 mm², 2 sets ≥160 Ah
208 48 V 6 mm², 2 sets ≥80 Ah
2500 W 252 12 V 16 mm², 2 sets ≥400 Ah
254 24 V 10 mm², 2 sets ≥200 Ah
258 48 V 6 mm², 2 sets ≥100 Ah
3000 W 302 12 V 16 mm², 2 sets ≥480 Ah
304 24 V 10 mm², 2 sets ≥240 Ah
308 48 V 6 mm², 2 sets ≥120 Ah
4000 W 402 12 V 25 mm², 2 sets ≥640 Ah
404 24 V 16 mm², 2 sets ≥320 Ah
408 48 V 10 mm², 2 sets ≥160 Ah
* One set contains one positive and one negative wire.
** Recommended capacity of the batteries during permanent power.
ѥ Warning!
Fire hazard!
If 2 sets of battery cables are recommended, both sets must also be installed. Failure
to do so can easily lead to overheating of the overloaded cables and connection points
and cause a dangerous cable fire.
⚠ Caution!
Please note the capacity!
An underrun of the recommended battery capacity can cause a loss of performance or
serious use restrictions as a result of voltage drops.
