SINUS/SINE INVERTER – CSI-/SSI-SERIES
]
35
Explanation of symbols
ѥ Warning!
Failure to comply with these instructions could result in death or serious injury
⚠ Caution!
Failure to comply these instructions can cause functional impairment or damage of the
device.
☝ Please note!
Further information for the operation of the device.
Scope of supply
Number Designation Number Designation
1 Unit Inverter Set Suitable ATO fuse
1 Unit 230 V cold-device plug 1 Unit Operating instructions
Contin-
uous
output
Model
CSI-/SSI
Input
voltage
recommended
battery cabel*
Battery
capacity**
300 W 32 12 V 4 mm², 1 set ≥50 Ah
34 24 V 2,5 mm², 1 set ≥25 Ah
38 48 V 2.5 mm², 1 set ≥12 Ah
500 W 52 12 V 6 mm², 1 set ≥100 Ah
54 24 V 4 mm², 1 set ≥50 Ah
58 48 V 2.5 mm², 1 set ≥25 Ah
1000 W 102 12 V 10 mm², 1 set ≥160 Ah
104 24 V 6 mm², 1 set ≥80 Ah
108 48 V 4 mm², 1 set ≥40 Ah
