ECTIVE
®
SINUS/SINE INVERTER – CSI-/SSI-SERIES
]
56
Functional diagram SSI-series (illustration of a 12 V-device)
1 2 3 4 5
bypass
function
shore power
inverter
function
battery
voltage
charge
current
solar charging
AC charger
function
OFF
OFF
OFF
ON
Phase
ON
OFF
ON ON
OFF
ON
OFF
OFF
14.4 V
20 A
4 A
daytime daytime
nighttime
20 A
3 A
20 A
40 A
14.4 V
13.8 V
13
V
13.8 V
11V 10.5 V
OFF OFF
ON ON
ON ON
ON
Scenario in
UPS Mode
