ECTIVE
®
SINUS/SINE INVERTER – CSI-/SSI-SERIES
]
58
If scenario 4 has occurred (discharging to 10,5 V*) the batteries are charged via solar
and shore power (for example in daylight) to prevent a battery damage as soon as
possible, until a voltage of 13 V* is reached. Afterwards the batteries are charged with
solar power only.
* All voltage values refer to 12 V. For 24 V: double value, for 48 V: quadruple value.
Safety features
☝ Please note!
Restart necessary!
The inverter is equipped with several safety features to protect the inverter and all its
components as for example the batteries.
The inverter is equipped with a thermic and electronic over-/undervoltage protection. If
the required values are exceeded or not reached, the device disconnects the AC output
and must be switched off and on again before restarting via the ON/OFF switch.
⚠ Caution!
The device remains switched on when the AC output is disconnected. There is a risk of
deep discharge of connected batteries due to the power consumption of this standby
mode.
The inverter disconnects the AC output in the following cases:
• internal temperature too high
• required output load too high
• input voltage too high or too low
Reason 12 V 24 V 48 V Action
risk of under-
voltage
10.8V±0.2V 21.6V±0.4V 43.2V±0.8V 2x acoustic signal
+ red LED flashing 2x
every 8 sec.,
inverter still working
