ECTIVE CSI34 User Manual

[
ECTIVE
®
SINUS/SINE INVERTER – CSI-/SSI-SERIES
]
59
Reason 12 V 24 V 48 V Action
total under-
voltage
10.2V±0.2V 20.4V±0.4V 40.8V±0.8V 3x acoustic signal
+ red LED flashes 3x
every 8 sec.,
automatic shutdown
overvoltage 15.5V±0.2V 31.0V±0.4V 62.0V±0.8V 4x acoustic signal
+ red LED flashing 4x
every 8 sec.,
automatic shutdown
overheating internal temperature >75°C 5x acoustic signal
+ red LED flashes 5x
every 8 sec.,
automatic shutdown
overload due
to powerful
consumers
regardless of the type 11x acoustic signal
+ red LED flashes con-
stantly until the error
is solved and device is
switched on again
short circuit
of consumers
regardless of the type red LED flashes
constantly until error
is solved and device is
switched on again
polarity
reversal
regardless of the type the fuses blow
undervoltage
ECO-Mode
11V±0.2V 22V±0.4V 44V±0.8V shift to mains priority
circuit
☝ Please note!
Exclusion of liability
Damages caused by polarity reversal and short circuits are excluded from liability.
