Acclarix AX3 Series Diagnostic Ultrasound System User Manual Measurements and Reports
- 82 -
No.
Cardiac Measurement
Description
Tool
1.8
LA Width
Left Atrium Width Diameter
1.9
Ao Asc
Ascending Aorta Diameter
1.10
AoD
Aortic Root Diameter
1.11
LVOT Diam
Left Ventricular Outflow Tract
1.12
RVOT Diam
Right Ventricular Outflow Tract
Section 2: Doppler Measurements
2.1
MV(Mitral
Valve)
E/A
E-wave Velocity/ A-wave Velocity
Caliper
MV PHT
Mitral Valve Pressure Half Time
MV Trace
Mitral Valve Trace
Trace
IVRT
Isovelocity Relaxation Time
Caliper
MV A Dur
Mitral Valve A-wave Duration
MV DecT
Mitral Valve Deceleration Time
2.2
TV(Tricuspi
d Valve)
TV Trace
Tricuspid Valve Trace
Trace
TV Vmax
Tricuspid Valve Maximum Velocity
Caliper
2.3
AoV(Aortic
Valve)
LVOT Trace
Left ventricular outflow tract Trace
Trace
LVOT Vmax
Left ventricular outflow tract maximum
Velocity
Caliper
AoV Trace
Aortic Valve Trace
Trace
AoV Vmax
Aortic Valve maximum Velocity
Caliper
2.4
PV
(Pulmonic
Valve)
PV Trace
Pulmonic Valve Trace
Trace
PV Vmax
Pulmonic Valve maximum Velocity
Caliper
2.5
P Vein
(Pulmonic
Vein)
PVein S Vel
Pulmonic Veins Systole Velocity
Caliper
PVein D Vel
Pulmonic Veins Diastole Velocity
PV A Vel
A Point Reverse Velocity
2.6
HR**
Heart rate
Caliper
Section 3: M-mode Measurements
3.1
Vent. Dim
(Ventricular
Diameter)
RVAWd
Right Ventricular Anterior Wall
Thickness at End-diastole
Caliper
RVIDd
Right Ventricular Internal Diameter at
end-diastole
IVSTd
Interventricular Septal Thickness at
End-diastole
LVIDd
Left Ventricular Internal Diameter at
End-diastole
LVPWd
Left Ventricular Posterior Wall
