Quick Start Guide
– 3 –
Each QSFP28 port has four LEDs that indicate valid links in the
following modes:
■
1 LED Green — 100 Gbps mode
■
1 LED Blue — 40 Gbps mode
■
1-4 LEDs Yellow — 25 Gbps breakout mode (four lanes)
■
1-4 LEDs Purple — 10 Gbps breakout mode (four lanes)
Switch Chassis
Size (WxDxH) 438.4 x 536 x 43.5 mm (17.26 x 21.1 x 1.71 in.)
Weight 10 kg (22.05 lb), with two installed PSUs
Temperature F2B Operating: 0° C to 45° C (32° F to 113° F)
B2F Operating: 0° C to 40° C (32° F to 104° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
Power
Consumption
550 Watts maximum
AC PSU
Power Rating 100–240 VAC, 50-60 Hz, 650 Watts
AC Input 100–240 VAC, 50-60 Hz, 6 A maximum
48 VDC PSU
Power Rating 48 VDC, 650 Watts
DC Input -36 V – -72 V, 16 A maximum
Regulatory Compliances
Emissions EN 55032:2015+AC:2016, Class A
EN 61000-3-2:2014, Class A
EN 61000-3-3:2013
FCC Class A
VCCI Class A
CCC GB 9254-2008, Class A
BSMI Class A, CNS 13438
Immunity EN 55024:2010+A1:2015
IEC 61000-4-2/3/4/5/6/8/11
Safety UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
CCC GB4943.1-2011
BSMI, CNS 14336-1
Taiwan RoHS CNS 15663
