快速安装指南
– 6 –
SFP/SFP+ SFP/SFP+
1000BASE-SX (ET4202-SX)
1000BASE-LX (ET4202-LX)
1000BASE-EX (ET4202-ZX)
1000BASE-ZX (ET4202-EX)
10GBASE-SR (ET5402-SR)
10GBASE-LR (ET5402-LR)
10GBASE-ER (ET5402-ER)
10GBASE-ZR (ET5402-ZR)
LED
PoE :
/ —
/ – PoE
漲♭鈺劲
(W x D x H)
ECS4620-28T / ECS4620-28T-DC / ECS4620-28P/
ECS4620-28F / ECS4620-28F-DC / ECS4620-28F-
2AC: 44.0 x 31.5 x 4.4 cm17.3 x 12.4 x 1.7
ECS4620-52T / ECS4620-52P / ECS4620-52P-2AC:
44.0 x 39.1 x 4.4 cm 17.3 x 15.4 x 1.7
ECS4620-28T: 3.7 kg 8.16
ECS4620-28T-DC: 3.7 kg 10.91
ECS4620-28P: 4.95 kg 9.92
ECS4620-28F: 3.8 kg 8.38
ECS4620-28F-DC: 3.8 kg 8.38
ECS4620-28F-2AC: 4.25 kg 9.36
ECS4620-52T: 4.8 kg 10.58
ECS4620-52P: 6.58 kg 14.51
ECS4620-52P-2AC: 7.97 kg 17.57
0 ° C~45 ° C 32 ° F~122 ° F
0 ° C~50 ° C 32 ° F~113 ° F
ECS4620-28P, ECS4620-28F 2AC )
: -40 ° C~70 ° C -40 ° F~158 ° F
规 10%~90%
*
ECS4620-28T: 100~ 240 V, 50-60 Hz, 1.5 A
ECS4620-28P: 100~240 V, 50-60 Hz, 10 A
ECS4620-28F: 100~240 V, 50-60 Hz, 2 A
ECS4620-52T: 100~240 VAC, 50-60 Hz, 2 A
ECS4620-52P: 50-60 Hz
100~127 VAC, 12 A
200~240 VAC, 6 A
ECS4620-28F-2AC: 100~240 VAC, 50-60 Hz, 2.5 A (
光 AC )
ECS4620-52P-2AC: 100~240 VAC, 50-60 Hz, 12 A (
光 AC )
ECS4620-28T-DC: 36~75 VDC, 2.5 A
ECS4620-28F-DC: 36~75 VDC, 3.82 A
ECS4620-28T: 50 W( 光
ECS4620-28T-DC: 50 W
ECS4620-28P: 515 W 光
ECS4620-28F: 50 W 光
ECS4620-28F-DC: 50 W
ECS4620-28F-2AC: 65 W 光
ECS4620-52T: 70 W 光
ECS4620-52P: 960 W 光
PoE
ECS4620-52P-2AC: 925 W 光
PoE
ECS4620-28P: 410 W
ECS4620-52P: 780 W
ECS4620-28T, ECS4620-28P,
ECS4620-28F, ECS4620-28T-DC, ECS4620-28F-DC, ECS4620-52T
ECS4620-52P
100-240 VAC 50-60 Hz, 12 A
12 VDC 10 A, -54.5 VDC 14.3 A
CE Mark
EN 55032, Class A
FCC Class A
EN 61000-3-2/3
VCCI Class A ( ECS4620-28F-2AC ECS4620-
52P-2AC)
BSMI ( ECS4620-28T/28T-DC/52T)
电
EN 61000-4-2/3/4/5/6/8/11
UL 60950-1 & CSA 60950-1
UL 62368-1 & CSA 62368-1
IEC 60950-1 & EN 60950-1
IEC 62368-1 & EN 62368-1
CNS14336-1 ( ECS4620-28T/28T-DC/
52T)
RoHS CNS15663 ( ECS4620-28T/28T-DC/52T)
* 100%
