VP3302 IP Phone User Manual
www.edge-core.com
8
2.1.2 Rear and Back side Panel of the VP3302
The rear and back side panel illustrations are shown in figure 2 and 3.
Main parts include:
3.
2.
1.
1. RJ-45 Ethernet Port
2. RJ-45 Ethernet Port
3. Power Adaptor Jack
4. Jack of line to handset
Figure 2. Rear Panel of the IP Phone
Phone
Figure 3. Back Side Panel of the IP
4.
