OPERATING INSTRUCTIONS
INTRODUCTION PARTS DESCRIPTION INSTALLATION OPERATING INSTRUCTIONS INTERNET UPDATES APPENDIX
37
USER GUIDE
After selecting yes, you’ll see a screen with 8 parameter data display
boxes. Each box represents an Injector. This screen is where you’ll
want to compare the injector balance rates in both Park and Drive.
In Park the values should not have a numerical value
higher than + or - 4.0, in Drive they should not be higher
than + or - 6.0
Note: The above injector balance screen shot represents a truck
with injector balance rates that are acceptable. The sample was
taken in park. You can see that there are no numbers higher than
+4.0 or -4.0 on the screen, so it’s safe to assume the injectors are
working properly.
