Edge Tub - Page 13

First remove the protective Chiller
Fitting Caps by rotating
counterclockwise. Then, install the
Inner Water Strainer by turning
clockwise onto the red “Inlet” fitting
on the Chiller. Ensure the Strainer O-
ring near the Chiller body is in place
(see image). The silver Water Strainer
Cover fits over the Inner Water Strainer
and should be tightened until hand
tight and the enclosure is flush with
the Chiller body.
Before connecting the hoses, ensure
that there is a Hose O-Ring in place
inside each end of the four Hose
Connection Fittings. If there is not, place
an o-ring from the spare parts bag to
avoid leaking. The green “Water In”
fitting on the Tub should connect to
the green “Outlet” on the Chiller. The
red “Water Out” fitting on the Tub
should connect to the red “Inlet” on
the Chiller. To tighten, thread on the
Hose Connection Fittings and rotate
clockwise. The threads should tighten
easily and smoothly. If resistance is felt
immediately, try attaching the hose
again. Hand tighten until resistance is
felt. Please Note: the Hose Connection
Fittings should be hand-tightened only;
do not use tools. Overtightening may
cause leaking or damage.
Check that the Chiller Drain Cap and
hoses are in place. Remove the plastic
and insert a filter into the Water Filter
Housing, and then fill with water.
Ensure the Filter Housing O-Ring is in
place in the Upper Water Filter Housing.
Install the Lower Water Filter Housing by
turning right if facing the back of the
Chiller until hand tight. Do not use the
filter wrench to tighten the water filter
housing. It is only for loosening. The
Tub can now be filled with water up to
the “Fill Level” line.
Overfilling may cause water to overflow
from the Tub for some users, though
you may fill to your preference.
Please refer to the Water Maintenance
Instructions for the weekly protocol on
checking the condition of the filter and
how and when to change it.
Step 4 – Install the
External Water Strainer
05 Setup Instructions
Step 6 – Fill the Tub
(see image).
Step 5 – Connect the
Chiller to the Tub
Step 7 – Open valves
Once the Tub has been filled, confirm
the Tub Valve Fittings are in the open
(parallel) position (see image). Ensure
this step has been completed to
prevent damage to Chiller, and the
valves are always in the open
(parallel) position any time you turn
your unit on. Damage will occur if the
valves are closed when the machine
is turned on!
(see image).
13
