9
Installation in a Sliding Window
1. Attach Grille
Attach the protective grille (baffle) to the window panel. Push on the grille firmly to ensure that
its four raised tabs are attached securely into the window panel.
2. Assemble Window Panel
To assemble the window panel, start by measuring the width of the window opening where
the window panel will be installed.
• If the inner width of the window is between 22” and 24” tall:
o Remove the adjustment panel from the window panel, and cut the window panel to the
same height as the window opening. Cut the side farthest from the exhaust opening.
• If the inner width of the window is between 24” and 36” tall:
o Slide the adjustment panel to fit the window frame height.
To Next Page
