6
Water System
When the water supply hose (No. 38) is connected with the main water supply, water will fill the water bin
(No. 57) through the float valve (No. 32) until water fills the bin enough to make the float valve close.
During ice-making stage, water is pumped from the water bin to the water distribution tube (No. 45.) The
water then flows over the surface of evaporator. Most of water goes back to the water bin. Some water is
frozen onto the evaporator little by little. When water in the bin falls below a certain level the float valve
will open and fill the bin again.
