Replacing Water System Components

Replacing the water pump

 Disconnect electrical power.

 Remove the rear cover

 Unplug the lines connected to the water pump, the water outlet tube and the water inlet tube.

 Loosen the screws and replace with a new one.

 Reverse the above steps to reassemble.

Replacing the water inlet valve

Note: If the water inlet valve does not work at all, or does not shut off tightly, it should be

replaced.

 Unplug or disconnect electrical power.

 Loosen the water supply pipe, remove the water panel, loosen 2 screws holding the water inlet

valve, unplug the lines and loosen the water valve outlet tube.

 Replace a new one, reverse the above step to reassemble.

Unscrew the water drain cap and drain off the waste water into a

bucket or other suitable drain port. Next, re-secure the drain cap

and tighten.
