EdgeStar Built-in Ice Maker 2
Parts Identification
Back View
Front View
Ice Scoop
Power Cord
Water inlet
Drain outlet
Water Supply Hose
Drain Hose
Door
Leveling Leg
Water distribution
Water trough
Float
Front louver panel
(Kickplate)
Evaporator (ice mold)
Ice storage bin
Control panel
