Edimax EW-7811Un V2 User Manual

16
V. Advanced Feature
WPS (Wi-Fi Protected Setup) is a simple, alternative way to establish
connections between WPS compatible devices when using the Wi-Fi Adapter
on a Windows computer. When WPS is activated in the correct manner for
two compatible devices, they will automatically connect to each other without
a password required.
V-1. Software WPS
1. To support WPS, driver installation is a prerequisite. Please refer to section
III to install the driver first.
2. On your Wi-Fi Router or AP, press the WPS button for the correct time
length to activate WPS.
Please check the instructions of your Wi-Fi
Router or AP to activate WPS correctly.
3. On the USB adapter, please refer to section III-2 and skip “Enter Password”
if the procedures are correct.
4. The process takes a while to establish connection. Once it’s done, you can
access the Internet right away.
WPS Button

Edimax EW-7811Un V2 Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Frequency range	2.4 - 2.4835 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	150 Mbit/s
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 11, 12, 24, 36, 48, 54, 72, 150 Mbit/s
Internal	No
Certification	CE (DoC), FCC
Component for	PC
Product color	Black
LED indicators	Activity, Link
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Sustainability certificates	RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	17.5 mm
Width	14.9 mm
Height	7.1 mm
Weight	2 g
