Edirol FA-66 - Connecting Various Types of Equipment

39
Basic connections and settings
fig.send-return
Connections
Connect output jacks 1-4 to your external mixer or other device.
Direct monitor volume
This adjusts the monitor volume.
Adjusting the direct monitor volume will not affect the recording level.
Connecting various types of equipment
Mixer, DJ Mixer, etc.
Computer
Guitar/Bass
Mic
CD/MD/cassette player,
MIDI sound module, etc.
Amplified speakers
FireWire cable
IEEE1394 connector
(FireWire connector,
iLink connector,
DV connector)
Adjust the level of
the input from a
synthesizer or other
device connected to
the INPUT 1/2 jacks.
