∃DISON Metal Clay Printing (Continued)
Annex1. Exchanging the Extruder for the Metal Clay Printing
Copper/Bronze/Steel paste
Take out output clay with the tile and dry it for 24 hours by natural drying or dry it
by warming for at least 1 hour using a dryer. Print-out has been completely dried ca
n be detached from the tile easily.
Prepare firing for dried sample using cube and carbon which are optional items.
Build up about 3cm of carbon on the cube and put the sample on it and bury the
Build up about 3cm of carbon on the cube and put the sample on it and bury the
sample entirely by pouring carbon on the sample as much as possible and then
close the cover.
<Comparison of set temperature and firing time by material>
Upon completion of firing, switch off the kiln and open the door to cool down
the heat enough. If the heat cools down to room temperature, finish work by taking
Set temperature: 980°C
Firing time: 4 hours total
Set temperature: 130°C>>843°C
Firing time: 9 hours total
* After set at 130°C, increase
by 130°C per an hour up to 843°C.
I.E
.
130°C>260°C>390°
C>520°C>650°C>780°C>843°C
Set temperature: 778°>>990°C
Firing time: 1 hour in 778°C,
additional firing in 990°C for
2 hours
∃DISON PRO User Manual V.1 30
the heat enough. If the heat cools down to room temperature, finish work by taking
the sample out of the cube and brushing the sample using stainless steel brush.
NOTE :
Cube and carbon are recyclable (only the part which has not changed into white ash by oxidation).
TIP :
Be careful of scald when use toast oven or kiln and especially, in case the output has been fired in
kiln, cool the output enough by opening the door at least an hour before take the printed object
out of the kiln.
When you print in the tile after dry in toast oven, the output will not be separated easily unless you
cool it enough so cool it for at least 30 minutes before you separate the output and then put it on
wire mesh and put in the kiln.
